Rapid Turnkey SMT PCBA Assembly Manufacturing Service with In-House CNC Fixture Plus 1 Hour Stencil
-
Highlight
Rapid Turnkey SMT Assembly
,In-House CNC Fixture
,1-Hour Stencil Service
-
Component Size0201 (0.6mm X 0.3mm)
-
Inspection100% AOI + X-Ray
-
Turnaround8 Hours
-
ProcessCNC Machining
-
Place of OriginShenzhen, China
-
Brand NameQHPCBA
-
CertificationIatf 16949, Iso 9001, Iso 13485, Ipc Class 3, Ipc-A-610, UL, ROHS, Reach
-
Model NumberQH-5053
-
Minimum Order Quantity1
-
Price$15
-
Packaging DetailsAnti-static + bubble wrap + cardboard box
-
Delivery Time8 Hours
-
Payment TermsWestern Union,T/T
-
Supply Ability100,000 PCS
Rapid Turnkey SMT PCBA Assembly Manufacturing Service with In-House CNC Fixture Plus 1 Hour Stencil
Rapid Turnkey SMT PCBA Assembly with In-House CNC Fixture and 1-Hour Stencil
QHPCBA provides factory-direct turnkey SMT PCBA assembly with three in-house capabilities that eliminate supply chain delays: laser stencil cutting, CNC fixture manufacturing, and high-speed SMT assembly — all under one roof in our Shenzhen factory.
Why Our Turnkey PCBA Service Is Faster
| Capability | QHPCBA (In-House) | Industry Standard (Outsourced) |
|---|---|---|
| SMT Stencil | 1 Hour | 1-3 Days |
| CNC Fixture | Same Day | 5-7 Days |
| SMT Assembly | 8 Hours | 3-7 Days |
| Engineering Review | 1-2 Hours | 12-24 Hours |
| Middleman Markup | 0% (Factory Price) | 15-40% Platform Fee |
In-House Capabilities
Laser SMT Stencil — 1 Hour
Fiber laser stencil cutter produces solder paste stencils with ±0.01mm accuracy within 1 hour. Electropolished finish ensures perfect paste release for fine-pitch components including 0201 and 01005 packages.
CNC Fixture Manufacturing — Same Day
Custom CNC-machined assembly fixtures from fiberglass (FR-4/G10) and aluminum alloy for reflow soldering pallets, wave solder fixtures, test jigs, and enclosure brackets.
High-Speed SMT Assembly — 8 Hours
Advanced pick-and-place lines for prototype and small-batch production supporting BGA (min 0.35mm pitch), QFN, fine-pitch ICs, and 01005 components with real-time production tracking.
Quality Assurance
- 100% AOI Inspection on every board
- X-Ray Analysis for BGA and QFN inspection
- Functional Testing with custom test fixtures
- IPC-A-610 Class 3 workmanship standard
Certifications
IATF 16949 | ISO 9001 | ISO 13485 | UL | IPC Class 3 | RoHS | REACH
Service Flexibility
| Option | Description |
|---|---|
| Turnkey | PCB fab + component sourcing + SMT + testing |
| Consigned | You supply components, we assemble and test |
| Prototype | 1-50 pieces, 8-hour turnaround |
| Small Batch | 50-5,000 pieces, competitive pricing |
Get Started
- Upload your Gerber file and BOM
- Review DFM feedback within 1-2 hours
- Receive assembled boards in as fast as 1 day
Contact QHPCBA today for your turnkey SMT PCBA assembly quotation. 1-hour stencil. Same-day CNC fixture. 8-hour assembly. Factory-direct pricing.
Our products are sold all over the world, you can rest assured.
