Nano-Coated Electropolished SMT Stencil Manufacturing Service with 1-Hour Turnaround Plus Fine Pitch Capability
-
Highlight
nano coated SMT stencil manufacturing
,electropolished laser cut stencil
,1 hour fine pitch PCB stencil
-
CoatingNano-Coated + Electropolished
-
Precision±0.01mm
-
Turnaround1 Hour
-
Min Aperture0.1mm (for 01005 Components)
-
MaterialStainless Steel 304
-
FrameStandard And VectorGuard Compatible
-
Place of OriginShenzhen, China
-
Brand NameQHPCBA
-
CertificationISO 9001, IPC Class 3, RoHS, REACH
-
Model NumberQHPCBA-STN-0808
-
Minimum Order Quantity1
-
Price$8
-
Packaging DetailsAnti-static + protective frame packaging
-
Delivery Time1 Hour
-
Payment TermsWestern Union, T/T
-
Supply Ability10,000 PCS
Nano-Coated Electropolished SMT Stencil Manufacturing Service with 1-Hour Turnaround Plus Fine Pitch Capability
Nano-Coated Electropolished SMT Stencil — 1 Hour Turnaround
QHPCBA produces nano-coated electropolished SMT stencils with 1-hour turnaround from our in-house fiber laser workshop. Engineered for fine-pitch assembly where paste release consistency directly determines first-pass yield.
Why Nano-Coating Matters
| Feature | Standard Stencil | Nano-Coated Stencil |
|---|---|---|
| Paste Release | Good | Excellent, even at 0.1mm aperture |
| Cleaning Interval | Every 5-10 prints | Every 20-30 prints |
| Bridging Risk | Moderate | Significantly Reduced |
| Stencil Life | 10,000 cycles | 30,000+ cycles |
| Best For | Standard pitch (>0.5mm) | Fine pitch (≤0.4mm), BGA, QFN, 0201/01005 |
Electropolishing Advantage
Laser cutting creates microscopic rough edges inside aperture walls — invisible to the eye but significant at fine pitch. Electropolishing removes these imperfections, creating ultra-smooth aperture walls that release solder paste cleanly with every print cycle.
Production Speed
Stencil production in 1 hour from Gerber approval. No outsourcing. No shipping delays. Your stencil is cut, electropolished, nano-coated, inspected, and ready on your SMT line — all from our Shenzhen factory.
Order your nano-coated SMT stencil today. 1-hour turnaround. 0.01mm precision. Perfect for fine-pitch BGA and micro-component assembly.
