High-Frequency Rogers PCB Prototype Manufacturing Service with Controlled Impedance 24-Hour Turnaround
-
Highlight
high frequency Rogers PCB prototype
,controlled impedance PCB manufacturing
,24 hour RF PCB fabrication
-
MaterialRogers 4350B, 4003C, FR-4 Hybrid
-
Dielectric Constant2.2-10.2
-
Layer Count1-8 Layers
-
Min Trace Width4mil (0.1mm)
-
Impedance Control±5% Tolerance
-
Turnaround24 Hours Standard
-
Place of OriginShenzhen, China
-
Brand NameQHPCBA
-
CertificationISO 9001, IPC Class 3, UL, RoHS, REACH
-
Model NumberQHPCBA-HF-0808
-
Minimum Order Quantity1
-
Price$25
-
Packaging DetailsAnti-static + bubble wrap + cardboard box
-
Delivery Time24 Hours
-
Payment TermsWestern Union, T/T
-
Supply Ability50,000 PCS
High-Frequency Rogers PCB Prototype Manufacturing Service with Controlled Impedance 24-Hour Turnaround
High-Frequency Rogers PCB Prototype Manufacturing
QHPCBA delivers Rogers high-frequency PCB prototypes with controlled impedance and 24-hour turnaround. Designed for RF, microwave, and high-speed digital applications where signal integrity is critical.
Rogers Materials We Stock
| Material | Dk | Best For |
|---|---|---|
| Rogers 4350B | 3.48 | RF power amplifiers, antennas, radar |
| Rogers 4003C | 3.38 | Microwave circuits, filters, couplers |
| FR-4 Hybrid | 4.2-4.6 | Mixed digital+RF designs, cost optimization |
Impedance Control
Every high-frequency PCB includes impedance control at ±5% tolerance verified with TDR measurement. Stack-up calculation performed by our engineering team before fabrication begins.
Applications
- 5G base station RF front-ends
- Satellite communication antennas
- Automotive radar (24/77 GHz)
- IoT gateway radios
- Medical imaging equipment
Upload your high-frequency PCB design for a DFM review. Rogers prototypes in 24 hours from our Shenzhen factory.
