Custom CNC Test Fixture Plus Bed-of-Nails Jig Manufacturing Service with 0.01mm Accuracy
-
Highlight
custom CNC test fixture manufacturing
,bed of nails testing jig service
,0.01mm precision test tooling
-
Fixture TypeBed-of-Nails, Boundary Scan, Functional Test
-
MaterialFiberglass FR-4, Acrylic, Aluminum
-
Probe TypeSpring-loaded Pogo Pins
-
Accuracy±0.01mm Pin Alignment
-
CustomizationAny Board Size And Layout
-
Place of OriginShenzhen, China
-
Brand NameQHPCBA
-
CertificationISO 9001, UL, RoHS, REACH
-
Model NumberQHPCBA-TF-0808
-
Minimum Order Quantity1
-
Price$12
-
Packaging DetailsAnti-static + custom foam + cardboard box
-
Delivery TimeSame Day
-
Payment TermsWestern Union, T/T
-
Supply Ability20,000 PCS
Custom CNC Test Fixture Plus Bed-of-Nails Jig Manufacturing Service with 0.01mm Accuracy
Custom CNC Test Fixture Manufacturing
QHPCBA fabricates custom CNC test fixtures and bed-of-nails jigs for PCB functional testing and ICT verification. Machined in-house from fiberglass, acrylic, or aluminum with ±0.01mm probe alignment accuracy.
Fixture Types
| Type | Description | Material |
|---|---|---|
| Bed-of-Nails ICT | Spring-loaded probes for in-circuit testing | Fiberglass + Acrylic |
| Functional Test | Custom interface for powered board testing | Aluminum + Acrylic |
| Boundary Scan | JTAG access fixture with minimal probes | Fiberglass FR-4 |
In-House Advantage
Unlike assembly houses that outsource fixture fabrication, QHPCBA machines test fixtures on our own CNC equipment. Same-day production. Same-day adjustments if probe positions need tweaking after first-article testing.
Send your PCB test point data (CAD or Excel). Same-day fixture fabrication from our Shenzhen factory. No minimum order.
