Frameless Nano Coated SMT Stencil Fine Pitch 1 Hour Quick Turn Shenzhen Manufacturer
-
Highlight
Frameless Nano Coated Stencil
,Fine Pitch SMT Stencil
,Quick Turn Stencil Shenzhen
-
TypeFrameless Nano Coated Stencil
-
Thickness0.08-0.20mm
-
Nano Coating1-2um Hydrophobic, Anti-adhesion
-
Fine Pitch0.20mm, For 0201 / 01005
-
Aperture Precision+/-0.01mm
-
ApplicationHDI, CSP, Fine Pitch PCB
-
FrameFrameless / Re-stencil
-
Turnaround1 Hour Rush, Quick Turn
-
Place Of OriginShenzhen, China
-
ComplianceRoHS, REACH
-
CertificationUL
-
Place of OriginShenzhen, China
-
Brand NameQHPCBA
-
CertificationUL
-
Model NumberQH-FL-NANO
-
Minimum Order Quantity1 Piece
-
PriceUSD 20-120 / Piece
-
Packaging DetailsFrameless flat protective packaging, export carton
-
Delivery Time1 hour rush delivery, quick turn
-
Payment TermsL/C, D/A, D/P, T/T, Western Union
-
Supply Ability500 PCS per Month
Frameless Nano Coated SMT Stencil Fine Pitch 1 Hour Quick Turn Shenzhen Manufacturer
Frameless Nano Coated SMT Stencil for Fine Pitch and HDI Printing
Our frameless nano coated stencil delivers clean solder paste release for fine pitch and high-density boards. Made in our Shenzhen factory with quick turn 1 hour service.
Key Features
- Frameless design for re-stenciling and compact storage
- Nano coating 1-2um hydrophobic layer for anti-adhesion and easy cleaning
- Supports fine pitch down to 0.20mm (0201 / 01005)
- Aperture precision +/-0.01mm
Specifications
- Thickness: 0.08-0.20mm
- Material: high-end stainless steel foil
- Application: HDI, CSP and fine pitch PCB solder paste printing
- Turnaround: 1 hour rush, quick turn
- Compliance: RoHS, REACH; UL certified
Need a quick turn frameless stencil? contact us with your Gerber and BOM.
