In-House Laser Stencil Fast SMT Prototyping Assembly Service for Rapid Builds

In-House Laser Stencil SMT Assembly for Fast Prototyping

Stencil lead time is one of the most underestimated causes of prototype delay, so we brought stencil manufacturing inside our own facility. QHPCBA is a precision PCB assembly manufacturer based in Shenzhen, China, focused on quick-turn SMT assembly and small-batch PCBA production for global hardware startups, R&D teams and OEM manufacturers. With our own SMT laser stencil workshop and an independent CNC fixture workshop, we respond faster, solve production issues in-house, and keep every prototype moving.

Why an In-House Stencil Workshop Matters

Most assembly houses order stencils from a third party, adding days before the first board can be printed. We cut laser stencils ourselves and can usually release them on the same day a stack-up or paste change is confirmed.

• Same-day stencil cutting
• Immediate re-cut after design revision
• Tighter control of aperture accuracy
• Fewer hand-offs and fewer delays

Better Printing, Better Yields

Stencil quality drives solder paste volume, which drives joint quality on fine-pitch parts. Controlling the stencil process internally lets us tune aperture design directly against real print results.

• Accurate paste deposition on fine pitch
• Reduced bridging and tombstoning
• Stable printing across a batch
• Direct feedback from line to stencil design

Fast Prototyping, End to End

From paste printing through placement, reflow and inspection, the whole prototype loop stays coordinated under one roof, which is what keeps build one and build two consistent.

• Rapid engineering changes
• Repeatable first-article results
• Short prototype cycle time
• Prototype-to-small-batch continuity

Manufacturing Capabilities

• Laser cut SMT stencils (in-house)
• Fine-pitch paste printing
• 01005 / 0201 chip placement
• BGA and QFN reflow
• AOI, X-Ray, functional test
• Lead-free soldering

Applications

• Fine-pitch prototype boards
• RF and high-density designs
• R&D iteration builds
• Engineering sample assembly
• Small-batch pilot production

At A Glance

Frequently Asked Questions

Why is an in-house stencil faster?
We do not wait for an external supplier, so stencils can be produced and revised on site the same day.

Does stencil quality affect yield?
Yes, controlling the stencil lets us tune paste volume for cleaner fine-pitch joints.

Can you re-cut a stencil after a change?
Yes, revisions are handled immediately in our workshop.
